807-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.156
| Part | Mounting Type | Color | Contact Finish | Read Out | Termination Rows | Material - Insulation | Contact Type | Termination | Gender | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Flange Feature | Number of Positions/Bay/Row | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Through Hole | Green | Gold | Dual | 1 | Diallyl Phthalate (DAP) | Semi Bellows | Wire Wrap | Female | Copper Alloy | 0.25 Ám | 10 Áin | 48 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 24 | |||||
 EDAC Inc. | Through Hole | Green | Tin | Dual | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Side Mount Opening Unthreaded | 12 | 2 | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | Through Hole | Green | Gold | Single | 1 | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 0.25 Ám | 10 Áin | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 24 | 0.156 " | 3.96 mm | 1 | |||
 EDAC Inc. | Through Hole | Green | Tin | Single | 1 | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 24 | 0.128 " | 3.25 mm | 1 | |||||
 EDAC Inc. | Right Angle Through Hole | Green | Gold | Single | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 0.25 Ám | 10 Áin | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 12 | 2 | |||||
 EDAC Inc. | Through Hole | Green | Tin | Dual | 1 | Diallyl Phthalate (DAP) | Semi Bellows | Solder Eyelet(s) | Female | Copper Alloy | 48 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | 24 | ||||||||
 EDAC Inc. | Board Edge Straddle Mount | Green | Gold | Dual | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 0.25 Ám | 10 Áin | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 12 | 2 | 0.156 " | 3.96 mm | Card Extender | ||
 EDAC Inc. | Through Hole | Green | Gold | Dual | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 0.25 Ám | 10 Áin | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Side Mount Opening Unthreaded | 12 | 2 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Through Hole | Green | Gold | Single | 1 | Diallyl Phthalate (DAP) | Semi Bellows | Wire Wrap | Female | Copper Alloy | 0.25 Ám | 10 Áin | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | 24 | 1 | |||||
 EDAC Inc. | Through Hole | Green | Tin | Dual | Diallyl Phthalate (DAP) | Semi Bellows | Solder | Female | Copper Alloy | 24 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 125 °C | -40 C | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 12 | 2 |
