C2225X Series

Manufacturer: KEMET

Catalog

6800PF 1500V ROHS COMPLIANT: YES

Part	Mounting Type	Thickness (Max) [Max]	Thickness (Max) [Max]	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Temperature Coefficient	Package / Case	Voltage - Rated	Voltage - Rated	Applications	Capacitance	Features	Ratings	Thickness (Max) [Max] [custom]	Thickness (Max) [Max] [custom]
KEMET C2225X682JFGACAUTO
KEMET C2225X102JZGACTU	MLCC Surface Mount	1.8 mm	0.071 in	5 %	-55 C	125 °C	0.22 in	6.4 mm	5.6 mm	0.252 in	C0G NP0	2225 (5763 Metric)	2.5 kV	2.5 kV	Boardflex Sensitive	0.001 µF	High Voltage Low ESL Soft Termination
KEMET C2225X104KFRAC7800	MLCC Surface Mount	2.7 mm	0.106 in	10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	1500 V	1.5 kV	Boardflex Sensitive	100000 pF	High Voltage Low ESL Soft Termination
KEMET C2225X393JDGACAUTO	MLCC Surface Mount	2.7 mm	0.106 in	5 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	C0G NP0	2225 (5763 Metric)	1000 V	1 kV	Automotive Boardflex Sensitive	0.039 µF	High Voltage Low ESL Soft Termination	AEC-Q200
KEMET C2225X125K2RAC7800	MLCC Surface Mount	1.55 mm	0.061 in	10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	200 VDC		Boardflex Sensitive	1.2 µF	Soft Termination
KEMET C2225X104KFRACAUTO	MLCC Surface Mount	2.7 mm	0.106 in	10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	1500 V	1.5 kV	Automotive Boardflex Sensitive	100000 pF	High Voltage Low ESL Soft Termination	AEC-Q200
KEMET C2225X223KGRAC7800	MLCC Surface Mount	2.7 mm	0.106 in	10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	2000 V	2 kV	Boardflex Sensitive	0.022 µF	High Voltage Low ESL Soft Termination
KEMET C2225X103KHRAC7800	MLCC Surface Mount			10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	3000 V	3 kV	Boardflex Sensitive	10000 pF	High Voltage Low ESL Soft Termination		0.087 in	2.2 mm
KEMET C2225X392JGGAC7800	MLCC Surface Mount	2.7 mm	0.106 in	5 %	-55 C	125 °C	0.22 in	6.4 mm	5.6 mm	0.252 in	C0G NP0	2225 (5763 Metric)	2000 V	2 kV	Boardflex Sensitive	3900 pF	High Voltage Low ESL Soft Termination
KEMET C2225X224KCRACAUTO	MLCC Surface Mount	1.8 mm	0.071 in	10 %	-55 C	125 °C	0.232 "	6.4 mm	5.9 mm	0.252 in	X7R	2225 (5763 Metric)	500 V		Automotive Boardflex Sensitive	0.22 µF	High Voltage Soft Termination	AEC-Q200
