337-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 20POS 0.156
| Part | Material - Insulation | Termination Rows | Gender | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Read Out | Mounting Type | Flange Feature | Number of Rows | Number of Positions/Bay/Row | Contact Finish | Number of Positions | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Card Type | Color | Contact Material | Termination | Features | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | 4-40 Threaded Insert Top Mount Opening | 1 | 20 Bay/Row | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Copper Alloy | Solder | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Wire Wrap | Card Guides | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Right Angle Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Wire Wrap | Card Guides | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Board Edge Straddle Mount | M3 Threaded Insert Top Mount Opening | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Solder | Card Extender | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 20 Bay/Row | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Copper Alloy | Wire Wrap | |||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Solder | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Solder | 2 | 2 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | Side Mount Opening Unthreaded | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Solder | 2 | 2 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Board Edge Straddle Mount | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Solder | Card Extender | 2 | 2 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Female | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Through Hole | 10 | Gold | 20 | Cantilever | -40 C | 105 ░C | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Green | Copper Alloy | Wire Wrap | 2 | 2 |
