POE60U Series
Manufacturer: Phihong USA
Beta
⌘K
IEEE802.3BT - POE DESKTOP C14 10
| Part | Output Connector | Input Connector | Current - Output | Voltage - Output | Number of Ports | Power (Watts) - Per Port | Voltage - Input [Max] | Voltage - Input [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Type | Compliance | Efficiency | Features | Mounting Type | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Approval Agency | Standard Number | Data Rate | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 40 °C | -10 °C | Midspan Injector | IEEE802.3bt | Level VI | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | cULus IEC | 60950-1 | ||
 Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 40 °C | -10 °C | Midspan Injector | IEEE802.3bt | Level VI | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | cULus IEC | 60950-1 | ||
Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 60 °C | -10 °C | Midspan Injector | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | cULus IEC | 60950-1 | 10 Mbps 100 Mbps 1000 Mbps | 80 % | ||
Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 40 °C | -10 °C | Midspan Injector | IEEE802.3bt | Level VI | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | cULus IEC | 60950-1 | ||
 Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 40 °C | -10 °C | Midspan Injector | IEEE802.3bt | OCP OVP SCP | Desktop | 163.2 mm | 6.43 in | 1.42 " | 65 mm | 2.56 in | 36 mm | CE cULus | 75 % | |||
Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 60 °C | -10 °C | Midspan Injector | Level VI | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | CE cULus | 10 Gbps | |||
 Phihong USA | RJ45 (Data Power) | IEC 320-C14 (Power) RJ45 (Data) | 1.07 A | 56 V | 1 | 60 W | 264 VAC | 90 VAC | 40 °C | -10 °C | Midspan Injector | IEEE802.3bt | Level VI | OCP OVP SCP | Desktop | 140 mm | 5.51 in | 1.42 " | 65 mm | 2.56 in | 36 mm | cULus IEC | 60950-1 |
