Wall Mount AC Adapters ac-dc, 15 Vdc, 2 A, SW, multi-blade, N/E/B/A blades, P6 center pos, level VI, MED
Wall Mount AC Adapters ac-dc, 15 Vdc, 2 A, SW, multi-blade, N/E/B/A blades, P6 center pos, level VI, MED
Wall Mount AC Adapters ac-dc, 15 Vdc, 2 A, SW, multi-blade, N/E/B/A blades, P6 center pos, level VI, MED
| Part | Polarization | Cord Length | Cord Length | No Load Power Consumption | Current - Output (Max) [Max] | Approval Agency | Input Type | Applications | Standard Number | Weight | Weight | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Power (Watts) | Region Utilized | Operating Temperature [Max] | Operating Temperature [Min] | Output Connector [diameter] | Output Connector | Output Connector [z] | Input Connector | Form | Efficiency | Output Connector [x] | Output Connector [custom] | Output Connector [custom] | Output Connector [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 1.66 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Sold Separately) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 18 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | 2.5 mm 5.5 mm | Barrel Plug R/A | 9.5 mm | Multi-Blade (Sold Separately) | Wall Mount | Level VI | ||||
 CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 4 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Sold Separately) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 5 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 20 W | International | 40 °C | 0 °C | 2.5 mm 5.5 mm | Barrel Plug | Multi-Blade (Sold Separately) | Wall Mount | Level VI | 9.5 mm | ||||
 CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 1.66 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Included) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 18 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | 2.5 mm 5.5 mm | Barrel Plug | Multi-Blade (Included) | Wall Mount | Level VI | 9.5 mm | ||||
CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 2 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Included) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 15 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | 2.5 mm 5.5 mm | Barrel Plug | Multi-Blade (Included) | Wall Mount | Level VI | 9.5 mm | ||||
CUI Inc. | 1.2 m | 47.2 in | 100 mW | 3 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Sold Separately) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 12 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 36 W | International | 40 °C | 0 °C | USB Micro | Multi-Blade (Sold Separately) | Wall Mount | Level VI | |||||||
 CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 1.66 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Included) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 18 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | Barrel Plug R/A | Multi-Blade (Included) | Wall Mount | Level VI | 9.5 mm | 5.5 mm | 2.1 mm | |||
CUI Inc. | 1.2 m | 47.2 in | 100 mW | 1.66 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Sold Separately) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 18 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | USB Micro | Multi-Blade (Sold Separately) | Wall Mount | Level VI | |||||||
CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 830 mA | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Sold Separately) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 36 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | 2.1 mm 5.5 mm | Barrel Plug | Multi-Blade (Sold Separately) | Wall Mount | Level VI | 9.5 mm | ||||
CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 620 mA | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Included) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 48 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 30 Watts | International | 40 °C | 0 °C | 2.1 mm 5.5 mm | Barrel Plug | Multi-Blade (Included) | Wall Mount | Level VI | 9.5 mm | ||||
CUI Inc. | Positive Center | 1.2 m | 47.2 in | 100 mW | 4 A | CB Scheme CSA EN FCC IEC PSE UL | Multi-Blade (Included) | Medical | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 | 0.441 lb | 200.03 g | 264 VAC | 90 VAC | 5 V | 32.5 mm | 1.28 " | 42.8 mm | 73.6 mm | 2.9 in | 1.69 " | 20 W | International | 40 °C | 0 °C | 2.5 mm 5.5 mm | Barrel Plug R/A | 9.5 mm | Multi-Blade (Included) | Wall Mount | Level VI |
