833-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 14POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Rows | Color | Gender | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Type | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Termination | Pitch | Pitch | Number of Positions | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Termination Rows [custom] | Flange Feature | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Single | 0.156 " | 3.96 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Single | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Dual | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | 14 | Non Specified - Dual Edge | 125 °C | -40 C | 7 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Single | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Cantilever | Dual | 0.116 " | 2.95 mm | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Dual Edge | 125 °C | -40 C | 7 | 2 | Floating Bobbin Flush Mount | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Single | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | Flush Mount Top Opening Unthreaded | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Dual | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Dual Edge | 125 °C | -40 C | 7 | 2 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Single | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | Side Mount Opening Unthreaded | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 1 | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Cantilever | Single | 0.156 " | 3.96 mm | Gold | 0.25 Ám | 10 Áin | Solder | 3.96 mm | 0.156 in | 14 | Non Specified - Single Edge | 125 °C | -40 C | 14 | Flush Mount Top Opening Unthreaded | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Cantilever | Dual | 0.116 " | 2.95 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | 3.96 mm | 0.156 in | 14 | Non Specified - Dual Edge | 125 °C | -40 C | 7 | 2 | Floating Bobbin Flush Mount | 2 |
