292227 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER SMD R/A 5POS 1.5MM
| Part | Contact Finish - Post | Style | Mounting Type | Contact Shape | Contact Type | Insulation Color | Insulation Height | Insulation Height | Insulation Material | Features | Shrouding | Contact Length - Mating [custom] | Contact Length - Mating [custom] | Termination | Contact Material | Voltage Rating | Current Rating (Amps) | Number of Rows | Number of Positions Loaded | Applications | Fastening Type | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Number of Positions | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | ||
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 18 | |
 TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Beige | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 9 | |
 TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Beige | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 16 | |
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 13 | |
 TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Beige | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 8 | |
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 2 | |
 TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Beige | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 15 | |
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 15 | |
TE Connectivity Raychem Cable Protection | Tin | Board to Cable/Wire | Surface Mount Right Angle | Square | Male Pin | Black | 4.9 mm | 0.193 in | Glass Filled Nylon 6T Polyamide (PA6T) | Board Guide Solder Retention | Shrouded - 4 Wall | 2.4 mm | 0.094 in | Solder | Brass | 50 VAC | Varies by Wire Gauge | 1 | All | General Purpose | Detent Lock | Header | -30 ░C | 105 ░C | UL94 V-0 | 12 |
