845-052 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 52POS 0.100
...
| Part | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Pitch [x] | Pitch [x] | Card Type | Number of Rows | Contact Material | Read Out | Color | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions | Flange Feature | Flange Feature | Material - Insulation | Contact Type | Gender | Contact Finish | Termination Rows | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | 3.25 mm | 0.128 in | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | |||
 EDAC Inc. | Through Hole Right Angle | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Single Edge | 1 | Copper Alloy | Single | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 1 | 52 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | ||
 EDAC Inc. | Through Hole Right Angle | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | 3.25 mm | 0.128 in | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | Side Mount Opening Unthreaded | ||
 EDAC Inc. | Through Hole Right Angle | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | Flush Mount Top Opening Unthreaded | 0.156 in | 3.96 mm | ||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | 3.25 mm | 0.128 in | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | Side Mount Opening Unthreaded | ||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Single Edge | 1 | Copper Alloy | Single | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 1 | 52 | Floating Bobbin Flush Mount | 0.116 in | 2.95 mm | ||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Single Edge | 1 | Copper Alloy | Single | Green | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 1 | 52 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Through Hole | 10 Áin | 0.25 Ám | 125 °C | -40 °C | 2.54 mm | 0.1 in | Non Specified - Dual Edge | 2 | Copper Alloy | Dual | Green | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 52 | Diallyl Phthalate (DAP) | Cantilever | Female | Gold | 2 | 26 | M3 Threaded Insert Top Mount Opening |
