4600X Series
Manufacturer: Bourns Inc.
Beta
⌘K
RESISTOR NETWORKS & ARRAYS 12PINS 12KOHMS ISOLATED
| Part | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Resistance (Ohms) | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Number of Pins | Supplier Device Package | Power Per Element | Tolerance | Mounting Type | Number of Resistors | Circuit Type | Temperature Coefficient | Resistance (Ohms) [custom] | Number of Resistors [custom] | Resistor-Ratio-Drift | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 12-SIP | -55 C | 125 °C | 12 kOhms | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 12 | 12-SIP | 300 mW | 2 % | Through Hole | 6 | Isolated | 100 ppm/°C | ||||
 Bourns Inc. | 9-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.898 in | 22.81 mm | 9 | 9-SIP | 200 mW | 2 % | Through Hole | 8 | Bussed | 100 ppm/°C | 220 Ohms | ||||
 Bourns Inc. | 8-SIP | -55 C | 125 °C | 1 MΩ | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.798 in | 20.27 mm | 8 | 8-SIP | 200 mW | 2 % | Through Hole | 7 | Bussed | 100 ppm/°C | ||||
 Bourns Inc. | 10-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.998 in | 25.35 mm | 10 | 10-SIP | 125 mW | 2 % | Through Hole | R2R Ladder | 100 ppm/°C | 50 kOhms 100 kOhms | 16 | ||||
 Bourns Inc. | 4-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.398 in | 10.11 mm | 4 | 4-SIP | 300 mW | 2 % | Through Hole | 2 | Isolated | 100 ppm/°C | 820 Ohms | 50 ppm/°C | |||
Bourns Inc. | 8-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.798 in | 20.27 mm | 8 | 8-SIP | 200 mW | 2 % | Through Hole | 7 | Bussed | 100 ppm/°C | 1k | ||||
Bourns Inc. | 8-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.798 in | 20.27 mm | 8 | 8-SIP | 300 mW | 2 % | Through Hole | 4 | Isolated | 100 ppm/°C | 1.8k | ||||
 Bourns Inc. | 9-SIP | -55 C | 125 °C | 33 kOhms | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.898 in | 22.81 mm | 9 | 9-SIP | 200 mW | 2 % | Through Hole | 8 | Bussed | 100 ppm/°C | ||||
Bourns Inc. | 12-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 12 | 12-SIP | 200 mW | 2 % | Through Hole | 11 | Bussed | 100 ppm/°C | 220 Ohms | 50 ppm/°C | |||
 Bourns Inc. | 5-SIP | -55 C | 125 °C | 5.08 mm | 0.2 in | 2.49 mm | 0.098 in | 0.498 " | 12.65 mm | 5 | 5-SIP | 200 mW | 2 % | Through Hole | 4 | Bussed | 100 ppm/°C | 100 Ohms |
