1825058 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
DIP / SIP SWITCH, 7 CIRCUITS, SLIDE, SURFACE MOUNT, SPST, 24 V, 25 MA
| Part | Actuator Level | Washable | Number of Positions | Circuit | Mounting Type | Actuator Type | Contact Material | Length | Length | Voltage Rating | Electrical Life | Pitch [x] | Pitch | Pitch [x] | Termination Style | Contact Finish | Current Rating (Amps) | Mechanical Life | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Height Above Board | Height Above Board |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Raised | 7 | SPST | Surface Mount | Standard | ||||||||||||||||||
 TE Connectivity Raychem Cable Protection | Raised | 8 | SPST | Surface Mount | Slide (Standard) | Copper Alloy | 22.3 mm | 0.878 in | 24 VDC | 1000 Cycles | 0.1 in | Full | 2.54 mm | Gull Wing | Gold | 100 mA | 1000 Cycles | -30 ░C | 85 °C | Polyphenylene Sulfide (PPS) | 5.5 mm | 0.217 in |
