M20-977 Series

Catalog

CONN, HEADER, 3POS, 1ROW, 2.54MM ROHS COMPLIANT: YES

Part	Mated Stacking Heights	Shrouding	Current Rating (Amps)	Mounting Type	Connector Type	Contact Finish - Mating	Style	Insulation Color	Contact Length - Post [x]	Contact Length - Post [x]	Termination	Pitch - Mating	Pitch - Mating	Insulation Height	Insulation Height	Fastening Type	Contact Finish - Post	Insulation Material	Contact Length - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Material Flammability Rating	Contact Material	Number of Rows	Contact Type	Contact Shape	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions
Harwin Inc. M20-9770342	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable	Gold	Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C
Harwin Inc. M20-9770542	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable	Gold	Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	5
Harwin Inc. M20-9772646	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable		Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	26
Harwin Inc. M20-9771646	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable		Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	16
Harwin Inc. M20-9771846	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable		Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	18
Harwin Inc. M20-9770946	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable		Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	9
Harwin Inc. M20-9773246	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable		Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C
Harwin Inc. M20-9773242	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable	Gold	Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C
Harwin Inc. M20-9770842	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable	Gold	Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	8
Harwin Inc. M20-9770242	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Unshrouded	3 A	Through Hole	Header Cuttable	Gold	Board to Board Cable	Black	0.122 in	3.1 mm	Solder	0.1 "	2.54 mm	0.1 in	2.54 mm	Push-Pull	Tin	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	11.48 mm	0.452 in	UL94 V-0	Brass	1	Male Pin	Square	All	-40 C	105 ░C	2
