896-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 36POS 0.125
| Part | Termination Rows | Material - Insulation | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Color | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Termination | Read Out | Number of Positions/Bay/Row | Card Type | Gender | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Material | Contact Type | Contact Finish | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Wire Wrap | Single | 36 | Non Specified - Single Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Wire Wrap | Dual | Non Specified - Dual Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | 2 | 2 | 18 | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Solder Eyelet(s) | Single | 36 | Non Specified - Single Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 4-40 Flush Mount Threaded Insert Top Opening | Board Edge Straddle Mount | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Solder | Dual | Non Specified - Dual Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | 2 | 2 | 18 | Card Extender | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 1 | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Wire Wrap | Single | 36 | Non Specified - Single Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | |||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Solder | Dual | Non Specified - Dual Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | 2 | 2 | 18 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Board Edge Straddle Mount | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Solder | Dual | Non Specified - Dual Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | 2 | 2 | 18 | Card Extender | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | M3 Threaded Insert Top Mount Opening | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Wire Wrap | Dual | Non Specified - Dual Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | 2 | 2 | 18 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 " | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Wire Wrap | Single | 36 | Non Specified - Single Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 1 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Solder | Single | 36 | Non Specified - Single Edge | Female | 0.25 Ám | 10 Áin | 36 | Copper Alloy | Cantilever | Gold |
