307-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Read Out | Number of Rows [custom] | Contact Material | Number of Positions/Bay/Row | Color | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Positions | Gender | Contact Finish | Flange Feature | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Right Angle Through Hole | 48 | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Through Hole | 48 | Female | Gold | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 48 | Female | Gold | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Through Hole | 48 | Female | Gold | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Through Hole | 48 | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Through Hole | 48 | Female | Gold | Floating Bobbin Flush Mount | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Right Angle Through Hole | 48 | Female | Gold | Flush Mount Top Opening Unthreaded | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 48 | Female | Gold | Floating Bobbin Flush Mount | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | 0.116 " | 2.95 mm | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | Board Edge Straddle Mount | 48 | Female | Tin | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Card Guides | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 3.96 mm | 0.156 in | Dual | 2 | Copper Alloy | 24 | Green | 0.25 Ám | 10 Áin | Board Edge Straddle Mount | 48 | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Card Extender Card Guides |
