QPD-35 Series
Manufacturer: Qualtek
Beta
⌘K
AC/DC CONVERTER 48V 35W
| Part | Voltage - Input [Max] | Voltage - Input [Min] | Efficiency | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Current - Output 1 | Approval Agency | Voltage - Output 1 | Applications | Features | Voltage - Isolation | Mounting Type | Number of Outputs | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Qualtek | 264 VAC | 90 VAC | 88 % | 2.5 " | 33 mm | 101.6 mm | 4 " | 63.5 mm | 1.3 in | 760 mA | CB CE cURus | 48 V | ITE (Commercial) | Adjustable Output DC Input Capable Universal Input | 3000 V | Chassis Mount | 1 | 35 W | 70 °C | -25 °C | Enclosed |
Qualtek | 264 VAC | 90 VAC | 87 % | 2.5 " | 33 mm | 101.6 mm | 4 " | 63.5 mm | 1.3 in | 1.5 A | CB CE cURus | 24 V | ITE (Commercial) | Adjustable Output DC Input Capable Universal Input | 3000 V | Chassis Mount | 1 | 35 W | 70 °C | -25 °C | Enclosed |
Qualtek | 264 VAC | 90 VAC | 86 % | 2.5 " | 33 mm | 101.6 mm | 4 " | 63.5 mm | 1.3 in | 2.4 A | CB CE cURus | 15 V | ITE (Commercial) | Adjustable Output DC Input Capable Universal Input | 3000 V | Chassis Mount | 1 | 35 W | 70 °C | -25 °C | Enclosed |
 Qualtek | 264 VAC | 90 VAC | 80 % | 2.5 " | 33 mm | 101.6 mm | 4 " | 63.5 mm | 1.3 in | 6 A | CB CE cURus | 5 V | ITE (Commercial) | Adjustable Output DC Input Capable Universal Input | 3000 V | Chassis Mount | 1 | 35 W | 70 °C | -25 °C | Enclosed |
