ELF-18 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CMC 1.2MH 3A 2LN TH

Part	Operating Temperature [Min]	Operating Temperature [Max]	Inductance @ Frequency	Height (Max) [Max]	Height (Max) [Max]	Mounting Type	Voltage Rating - AC	Current Rating (Max) [Max]	Number of Lines	Package / Case	Package / Case	DC Resistance (DCR) (Max)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Height (Max)	Height (Max) [Max] [z]	Height (Max) [Max] [z]	DC Resistance (DCR) (Max) [Max]	Filter Type	Size / Dimension [x]	Size / Dimension [y]
Panasonic Industrial Automation Sales ELF-18D420F	-20 C	105 ░C	1.2 mH	20.5 mm	0.807 "	Through Hole	250 V	3 A	2	4 Lead	Vertical	43 mOhm
Panasonic Industrial Automation Sales ELF-18D850C				40 mm	1.575 in	Through Hole		3 A	2	4 Lead	Vertical	97 mOhm	1.417 in	1.004 in	36 mm	25.5 mm
Panasonic Industrial Automation Sales ELF-18D417	-20 C	105 ░C	1 kHz 18 mH	20.5 mm	0.807 "	Through Hole	250 V	700 mA	2	4 Lead	Vertical	700 mOhm
Panasonic Industrial Automation Sales ELF-18N004A					1.083 in	Through Hole		400 mA	2	4 Lead	Vertical	2.72 Ohm	0.709 in	1.083 in	18 mm		27.5 mm	27.5 mm
Panasonic Industrial Automation Sales ELF-18D290S						Through Hole		1.1 A	2	4 Lead	Vertical	277 mOhm	0.827 in	0.63 in	21 mm	16 mm			0.886 in	22.5 mm
Panasonic Industrial Automation Sales ELF-18N020A					1.083 in	Through Hole		2 A	2	4 Lead	Vertical		0.709 in	1.083 in	18 mm		27.5 mm	27.5 mm			130 mOhm
Panasonic Industrial Automation Sales ELF-18D656J				34.6 mm	1.362 in	Through Hole		1.6 A	2	4 Lead	Vertical	225 mOhm	0.827 in	1.142 in	21 mm	29 mm
Panasonic Industrial Automation Sales ELF-18D604	-20 C	105 ░C	4.7 mH		0.925 in	Through Hole	250 V	2 A	2	4 Lead	Vertical	125 mOhm	1.122 in	1.142 in	28.5 mm	29 mm		23.5 mm
Panasonic Industrial Automation Sales ELF-18D650P	-20 C	105 ░C		34.6 mm	1.362 in	Through Hole		700 mA	2	4 Lead	Vertical				29 mm	21 mm						Power Line	1.142 in	0.827 "
Panasonic Industrial Automation Sales ELF-18D650J				34.6 mm	1.362 in	Through Hole		1.3 A	2	4 Lead	Vertical	309 mOhm			29 mm	21 mm							1.142 in	0.827 "
