3612 Series
Manufacturer: Belden Inc.
Beta
⌘K
CAT6E 4PR U/UTP CMR RIB VIOLET
| Part | Number of Conductors | Ratings | Conductor Insulation | Conductor Insulation | Usage | Features | Conductor Material | Jacket Color | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Cable Type | Wire Gauge | Length | Length | Conductor Strand |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Purple | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Yellow | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Blue | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Orange | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Yellow | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | White | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 762 m | 2500 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Gray | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | White | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Black | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
Belden Inc. | 8 | UL Style CMR | Polyolefin | PO | Ethernet | Rip Cord | Copper Bare | Blue | 300 VDC | 5.87 mm | 0.231 in | Poly-Vinyl Chloride (PVC) Riser | Multi-Pair Cat6 | 23 AWG | 304.8 m | 1000 ft | Solid |
