AWHW2-26 Series
Manufacturer: Assmann WSW Components
Catalog
CONN HEADER R/A 26POS 2MM
| Part | Contact Material | Row Spacing - Mating | Row Spacing - Mating | Shrouding | Fastening Type | Current Rating (Amps) | Style | Number of Positions Loaded | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Connector Type | Number of Rows [custom] | Contact Shape | Contact Length - Post [custom] | Contact Length - Post | Contact Finish - Mating | Mounting Type | Material Flammability Rating | Insulation Height | Insulation Height | Contact Length - Mating | Contact Length - Mating | Contact Finish Thickness - Mating | Pitch - Mating | Pitch - Mating | Features | Insulation Material | Insulation Color | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Assmann WSW Components | Brass | 2 mm | 0.079 in | Shrouded - 4 Wall | Push-Pull | 1.5 A | Board to Cable/Wire | All | Male Pin | -40 C | 105 ░C | 26 | Header | 2 | Square | 0.11 in | 2.79 mm | Gold | Right Angle Through Hole | UL94 V-0 | 0.217 in | 5.51 mm | 4 mm | 0.157 in | Flash | 0.079 " | 2 mm | Keying Slot | Glass Filled Nylon 9T Polyamide (PA9T) | Black | Solder |
 Assmann WSW Components | Brass | 2 mm | 0.079 in | Shrouded - 4 Wall | Push-Pull | 1.5 A | Board to Cable/Wire | All | Male Pin | -40 C | 105 ░C | 26 | Header | 2 | Square | Gold | Surface Mount | UL94 V-0 | 0.22 in | 5.6 mm | 4 mm | 0.157 in | Flash | 0.079 " | 2 mm | Keying Slot Pick and Place | Glass Filled Nylon 9T Polyamide (PA9T) | Black | Solder |
