LDH-65 Series

Catalog

DC-DC STEP-UP CONSTANT CURRENT L

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Topology	Voltage - Input (Min) [Min]	Voltage - Output [Max]	Voltage - Output [Min]	Dimming	Approval Agency	Type	Voltage - Input (Max) [Max]	Efficiency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Current - Output (Max) [Max]	Features	Termination Style	Number of Outputs	Package / Case
MEAN WELL USA Inc. LDH-65-1050W	Chassis Mount	60 °C	-40 C	63 W	Boost	9.5 V	60 V	12.5 V	Analog PWM	CE EAC	Constant Current	32 V	95.5 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	1.05 A	OVP SCP	Wire Leads	1
MEAN WELL USA Inc. LDH-65-1050	Through Hole	60 °C	-40 C	63 W	Boost	9.5 V	60 V	12.5 V	Analog PWM	CE EAC	Constant Current	32 V	95.5 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	1.05 A	OVP SCP		1	6-DIP Module
MEAN WELL USA Inc. LDH-65-1750W	Chassis Mount	60 °C	-40 C	75 W	Boost	9.5 V	37 V	12.5	Analog PWM	CE EAC	Constant Current	32 V	96 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	1.75 A	OVP SCP	Wire Leads	1
MEAN WELL USA Inc. LDH-65-1400	Through Hole	60 °C	-40 C	64 W	Boost	9.5 V	46 V	12.5 V	Analog PWM	CE EAC	Constant Current	32 V	95 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	1.4 A	OVP SCP		1	6-DIP Module
MEAN WELL USA Inc. LDH-65-700W	Chassis Mount	60 °C	-40 C	56 W	Boost	9.5 V	80 VDC	12.5 V	Analog PWM	CE EAC	Constant Current	32 V	95 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	700 mA	OVP SCP	Wire Leads	1
MEAN WELL USA Inc. LDH-65-1400W	Chassis Mount	60 °C	-40 C	64 W	Boost	9.5 V	46 V	12.5 V	Analog PWM	CE EAC	Constant Current	32 V	95 %	53 mm	2.09 "	0.89 "	22.7 mm	2.95 "	75 mm	1.4 A	OVP SCP	Wire Leads	1
