ECE-A1 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

Catalog

CAP ALUM 22UF 20% 10V RADIAL TH

...

Part	Package / Case	Applications	Voltage - Rated	Polarization	Capacitance	Operating Temperature [Max]	Operating Temperature [Min]	Lifetime @ Temp.	Mounting Type	Tolerance	Ripple Current @ High Frequency	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ Low Frequency	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales ECE-A1AKA220B	Radial Can	General Purpose	10 V	Polar	22 µF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %	59.5 mA
Panasonic Industrial Automation Sales ECE-A1HN101U	Radial Can	General Purpose	50 VDC	Bi-Polar	100 µF	85 °C	-40 °C	2000 Hrs	Through Hole	20 %	425 mA	20 mm	0.787 "	250 mA	5 mm	0.197 in	10 mm	0.394 in
Panasonic Industrial Automation Sales ECE-A1AN222U	Radial Can	General Purpose	10 V	Bi-Polar	2200 µF	85 °C	-40 °C	2000 Hrs	Through Hole	20 %	1.173 A	25 mm	0.984 "	690 mA	7.5 mm	0.295 in	16 mm	0.63 in
Panasonic Industrial Automation Sales ECE-A1VKS3R3I	Radial Can	General Purpose	35 V	Polar	3.3 µF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %				16 mA	2.5 mm	0.098 in	4 mm	0.157 in	0.236 in	6 mm
Panasonic Industrial Automation Sales ECE-A1EN4R7U	Radial Can	General Purpose	25 VDC	Bi-Polar	4.7 µF	85 °C	-40 °C	2000 Hrs	Through Hole	20 %	42.5 mA	12 mm	0.472 "		2 mm	0.079 in	5 mm	0.197 "
Panasonic Industrial Automation Sales ECE-A1AKS220I	Radial Can	General Purpose	10 V	Polar	22 µF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %				35 mA	2.5 mm	0.098 in	5 mm	0.197 "	0.236 in	6 mm
Panasonic Industrial Automation Sales ECE-A1AKA101B	Radial Can	General Purpose	10 V	Polar	100 µF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %	136 mA	8 mm	0.315 in	80 mA	5 mm	0.197 in	6.3 mm	0.248 in
Panasonic Industrial Automation Sales ECE-A1EKS330I	Radial Can	General Purpose	25 VDC	Polar	33 ÁF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %				65 mA	2.5 mm	0.098 in	6.3 mm	0.248 in	0.236 in	6 mm
Panasonic Industrial Automation Sales ECE-A1AN471UB	Radial Can	General Purpose	10 V	Bi-Polar	470 µF	85 °C	-40 °C	2000 Hrs	Through Hole	20 %	578 mA	17 mm	0.669 in	340 mA	5 mm	0.197 in	10 mm	0.394 in
Panasonic Industrial Automation Sales ECE-A1VKA470Q	Radial Can	General Purpose	35 V	Polar	47 µF	85 °C	-40 °C	1000 Hrs	Through Hole	20 %	144.5 mA	8 mm	0.315 in	85 mA			8 mm	0.315 "
