153.5631.6151 Series

Fuse - BF1 32V / 2000A DC, 150A 10 pc

Catalog

Fuse - BF1 32V / 2000A DC, 150A 10 pc

Part	DC Cold Resistance	Fuse Type	Mounting Type	Voltage Rating - DC	Response Time	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Color	Melting I²t	Approval Agency	Package / Case	Current Rating (Amps)	Breaking Capacity @ Rated Voltage
Littelfuse/Commercial Vehicle Products 153.5631.6151	0.00029 Ohms	Automotive	Bolt Mount	32 V	Slow Blow	0.472 "	12 mm	0.63 "	0.323 "	8.2 mm	16 mm	Gray	83400	ISO UL	Auto Link	150 A	2 kA

Fuse - BF1 32V / 2000A DC, 150A 10 pc

• Grey housing indicates 150 A rating

• Interrupting rating of 2000 A at 32 V dc

• Tin-plated copper alloy terminals

• Refers to ISO 8820-5:2015

• UL Recognized in Canada and United States as a UL Special Purpose Fuse

This 150 A BF1 32V bolt-down automotive fuse employs SLO-BLO® technology to provide time-delayed protection for high-current wiring harnesses.
