172-E37 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 37POS PNL MNT
| Part | Contact Material | Wire Gauge [Min] | Wire Gauge [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Color | Dielectric Material | Flange Feature | Shell Size, Connector Layout | Shell Size, Connector Layout | Mounting Type | Connector Type | Number of Rows [custom] | Current Rating (Amps) | Connector Style | Number of Positions | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Contact Finish | Contact Finish Thickness | Contact Type | Material Flammability Rating | Termination | Features | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | 4-40 | 4 | DC C | Panel Mount | Receptacle Female Sockets | 2 | 5 A | D-Sub | 37 | Steel | Yellow Chromate Plated | Gold | Flash | Signal | UL94 V-0 | |||
 NorComp Inc. | Brass | 100 °C | -50 °C | White | Polyamide (PA6T) Nylon 6T | Board Side (4-40) | 4 | DC C | Panel Mount Through Hole | Receptacle Female Sockets | 2 | 5 A | D-Sub | 37 | Steel | Yellow Chromate Plated | Gold | Flash | Signal | UL94 V-0 | Solder | ||||
 NorComp Inc. | Brass | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | Cable Side (4-40) | 4 | DC C | Panel Mount | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Gold | Flash | Signal | UL94 V-0 | Grounding Indents | ||||||
 NorComp Inc. | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) Glass Filled | 4-40 | 4 | DC C | Panel Mount Through Hole | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Steel | Yellow Chromate Plated | Gold | Flash | Signal | UL94 V-0 | Solder | |||||
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | Cable Side (4-40) Mating Side Female Screwlock (4-40) | 4 | DC C | Panel Mount | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Steel | Yellow Chromate Plated | Gold | Flash | Signal | UL94 V-0 | Board Lock | ||
 NorComp Inc. | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) Glass Filled | Board Side (4-40) | 4 | DC C | Panel Mount Through Hole | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Gold | Flash | Signal | UL94 V-0 | Solder | Grounding Indents | ||||||
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | Cable Side (4-40) Mating Side Female Screwlock (4-40) | 4 | DC C | Panel Mount | Receptacle Female Sockets | 2 | 5 A | D-Sub | 37 | Gold | Flash | Signal | UL94 V-0 | Board Lock | Nickel Plated Steel | |||
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | Housing/Shell (Unthreaded) | 4 | DC C | Panel Mount | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Gold | Flash | Signal | UL94 V-0 | Grounding Indents | ||||
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | 4-40 | 4 | DC C | Panel Mount | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Gold | Flash | Signal | UL94 V-0 | Grounding Indents | ||||
 NorComp Inc. | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | White | Polybutylene Terephthalate (PBT) | Housing/Shell (Unthreaded) | 4 | DC C | Panel Mount | Plug Male Pins | 2 | 5 A | D-Sub | 37 | Steel | Yellow Chromate Plated | Gold | Flash | Signal | UL94 V-0 |
