PEH532R Series
Manufacturer: KEMET
Beta
⌘K
CAP ALUM 2200UF 20% 200V SNAP TH
| Part | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Ripple Current @ High Frequency | Capacitance | ESR (Equivalent Series Resistance) | Package / Case | Polarization | Tolerance | Height - Seated (Max) [Max] [z] | Height - Seated (Max) | Applications | Lead Spacing | Lead Spacing | Voltage - Rated | Ripple Current @ Low Frequency | Lifetime @ Temp. | Size / Dimension [diameter] | Size / Dimension [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | Through Hole | -40 C | 105 ░C | 8.7 A | 2200 µF | 67 mOhm | Radial Can - Snap-In | Polar | 20 % | 2.165 in | 55 mm | General Purpose | 0.394 in | 10 mm | 200 VDC | 3.1 A | 2000 Hrs | 1.378 " | 35 mm |
