HDF-V15 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, IP67, HIGH DENSITY, PLUG, NANOOK SERIES, 15 CONTACTS, DE, SOLDER
| Part | Dielectric Material | Color | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Connector Style | Flange Feature | Termination | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish | Shell Material, Finish | Current Rating (Amps) | Features | Connector Type | Number of Positions | Ingress Protection | Contact Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Material Flammability Rating | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Grounding Indents | Plug Male Pins | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 30 Áin | 0.76 Ám | 3 | UL94 V-0 | |
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Board Lock Grounding Indents | Plug Male Pins | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 3 | UL94 V-0 | Flash | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Board Lock | Receptacle Female Sockets | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 30 Áin | 0.76 Ám | 3 | UL94 V-0 | |
NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Grounding Indents | Plug Male Pins | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 3 | UL94 V-0 | Flash | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Receptacle Female Sockets | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 30 Áin | 0.76 Ám | 3 | UL94 V-0 | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Board Lock Grounding Indents | Plug Male Pins | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 30 Áin | 0.76 Ám | 3 | UL94 V-0 | |
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Board Lock | Receptacle Female Sockets | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 3 | UL94 V-0 | Flash | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Black | Brass | 85 °C | -25 °C | D-Sub High Density | 4-40 Mating Side Female Screwlock | Solder | (DE E) High Density | 1 | Gold | Nickel Plated Steel | 3 A | Receptacle Female Sockets | 15 | IP67 - Dust Tight Waterproof | Signal | Panel Mount Through Hole | 3 | UL94 V-0 | Flash |
