833-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Read Out | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Number of Positions | Mounting Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Termination | Color | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Positions/Bay/Row [custom] | Termination Rows | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 3.96 mm | 0.156 in | Dual | Cantilever | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 18 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 3.96 mm | 0.156 in | Single | Cantilever | 0.128 " | 3.25 mm | Non Specified - Single Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 1 | 36 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 3.96 mm | 0.156 in | Single | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 1 | 36 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 3.96 mm | 0.156 in | Single | Cantilever | 0.128 " | 3.25 mm | Non Specified - Single Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 1 | 36 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 3.96 mm | 0.156 in | Single | Cantilever | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Single Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 1 | 36 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 125 °C | -40 C | 3.96 mm | 0.156 in | Single | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Single Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 1 | 36 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 3.96 mm | 0.156 in | Dual | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 18 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 3.96 mm | 0.156 in | Dual | Cantilever | M3 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 18 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 3.96 mm | 0.156 in | Dual | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 18 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | 3.96 mm | 0.156 in | Dual | Cantilever | Non Specified - Dual Edge | 36 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Green | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 18 |
