9S0812 Series

Catalog

FAN AXIAL 80X25MM 12VDC WIRE

Part	Lifetime @ Temp.	Voltage Range [Max]	Voltage Range [Min]	Current Rating (Amps)	Material - Frame	Material - Blade	Noise	Features	Power (Watts)	Weight	Weight	Approval Agency	Bearing Type	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [z]	Size / Dimension [x]	Width [y]	Fan Type	RPM	Termination	Voltage - Rated	Static Pressure	Static Pressure	Air Flow	Air Flow
Sanyo Denki America Inc. 9S0812L4D01	40000 Hrs	13.8 VDC	6 VDC	50 mA	Plastic	Plastic	16 dB	Locked Rotor Sensor	600 mW	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2000 RPM	3 Wire Leads	12 VDC	18.2 Pa	0.073 in H2O	23.3 CFM	0.652 mł/min
Sanyo Denki America Inc. 9S0812F4D011	40000 Hrs	13.8 VDC	5 VDC	110 mA	Plastic	Plastic	24 dB	Locked Rotor Sensor	1.32 W	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2800 RPM	3 Wire Leads	12 VDC	35.6 Pa	0.143 in H2O	32.8 CFM	0.918 mł/min
Sanyo Denki America Inc. 9S0812L402	40000 Hrs	13.8 VDC	6 VDC	50 mA	Plastic	Plastic	16 dB		600 mW	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2000 RPM	2 Wire Leads	12 VDC	18.2 Pa	0.073 in H2O	23.3 CFM	0.652 mł/min
Sanyo Denki America Inc. 9S0812F4D01	40000 Hrs	13.8 VDC	5 VDC	110 mA	Plastic	Plastic	24 dB	Locked Rotor Sensor	1.32 W	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2800 RPM	3 Wire Leads	12 VDC	35.6 Pa	0.143 in H2O	32.8 CFM	0.918 mł/min
Sanyo Denki America Inc. 9S0812H401	40000 Hrs	13.2 VDC	5 VDC	0.23 A	Plastic	Plastic	31 dB(A)	Locked Rotor Protection Speed Sensor (Tach)	2.76 W	0.167 lb	75.75 g	CSA UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	3400 RPM	3 Wire Leads	12 VDC	49.8 Pa	0.2 in H2O	39.5 CFM	1.11 m³/min
Sanyo Denki America Inc. 9S0812F401	40000 Hrs	13.8 VDC	5 VDC	110 mA	Plastic	Plastic	24 dB	Locked Rotor Protection Speed Sensor (Tach)	1.32 W	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2800 RPM	3 Wire Leads	12 VDC	35.6 Pa	0.143 in H2O	32.8 CFM	0.918 mł/min
Sanyo Denki America Inc. 9S0812M402	40000 Hrs	13.8 VDC	5 VDC		Plastic	Plastic	22 dB(A)		960 mW	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2500 RPM	2 Wire Leads	12 VDC	27.4 Pa	0.11 in H2O	29.3 CFM	0.82 m³/min
Sanyo Denki America Inc. 9S0812L4021	40000 Hrs	13.8 VDC	6 VDC	50 mA	Plastic	Plastic	16 dB		600 mW	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2000 RPM	2 Wire Leads	12 VDC	18.2 Pa	0.073 in H2O	23.3 CFM	0.652 mł/min
Sanyo Denki America Inc. 9S0812H4011	40000 Hrs	13.2 VDC	5 VDC	0.23 A	Plastic	Plastic	31 dB(A)	Locked Rotor Protection Speed Sensor (Tach)	2.76 W	0.167 lb	75.75 g	CSA UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	3400 RPM	3 Wire Leads	12 VDC	49.8 Pa	0.2 in H2O	39.5 CFM	1.11 m³/min
Sanyo Denki America Inc. 9S0812P4M01	40000 Hrs	13.8 VDC	5 VDC		Plastic	Plastic	22 dB(A)	Locked Rotor Protection PWM Control Speed Sensor (Tach)	1.32 W	0.167 lb	75.75 g	CSA TUV UL	Ball	70 °C	-10 °C	80 mm	80 mm	25 mm	Tubeaxial	2800 RPM	4 Wire Leads	12 VDC	27.4 Pa	0.11 in H2O	29.3 CFM	0.82 m³/min
