F92ERL Series

Catalog

FIBER OPTIC CABLE, SINGLEMODE, 9ΜM / 125ΜM, LC DUPLEX TO LC DUPLEX, 2 M

Part	2nd Connector	Color - Connectors	Ratings	Insertion Loss	Cable Type	Color - Cable	Type	Operating Temperature [Min]	Operating Temperature [Max]	Return Loss	Cable Diameter [diameter]	Cable Diameter [diameter]	1st Connector	Fiber Type	Features	Length - Overall [x]	Length - Overall [x]	Bend Radius [radius]	Length - Overall	Length - Overall	Length - Overall [custom]
Panduit Corp F92ERLNLNSNM002	LC Duplex	Blue	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	6.6 ft	2 m	16 mm
Panduit Corp F92ERLNSNSNM018	SC Duplex	Blue	OFNR	0.35 dB 0.5 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-10 °C	60 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord			16 mm	18 m	59 ft
Panduit Corp F92ERLNLNSNM001	LC Duplex	Blue	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	3.3 ft	1 m	16 mm
Panduit Corp F92ERLNLNSNM033	LC Duplex	Black	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	108.3 '	33 m	16 mm
Panduit Corp F92ERLNSNSNM030	SC Duplex	Blue	OFNR	0.35 dB 0.5 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-10 °C	60 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	98.4 ft		16 mm	30 m
Panduit Corp F92ERLNSNSNM031	SC Duplex	Blue	OFNR	0.35 dB 0.5 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-10 °C	60 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	101.7 ft	31 m	16 mm
Panduit Corp F92ERLNSNSNM019	SC Duplex	Blue	OFNR	0.35 dB 0.5 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-10 °C	60 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	62.3 ft	19 m	16 mm
Panduit Corp F92ERLNLNSNM040	LC Duplex	Black	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord	131.2 ft		16 mm	40 m
Panduit Corp F92ERLNLNSNM021	LC Duplex	Black	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord			16 mm	21 m	68.9 ft
Panduit Corp F92ERLNLNSNM042	LC Duplex	Black	OFNR	0.25 dB	Twin Zip	Yellow	Duplex OS2 Singlemode	-20 C	70 °C	55 dB	0.06 in	1.6 mm	LC Duplex	9/125	Riser Zipcord			16 mm	42 m		137.8 ft
