RER-J2 Series
Manufacturer: Dinkle Corporation, USA
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
RELAY GEN PURPOSE SPDT 5A 120V
| Part | Coil Resistance | Features | Coil Current | Must Operate Voltage | Contact Form | Coil Voltage | Operate Time | Release Time | Coil Type | Relay Type | Mounting Type | Switching Voltage AC (Max) | Switching Voltage DC (Max) | Contact Rating (Current) | Contact Material | Operating Temperature (Min) | Operating Temperature (Max) | Quick Connect Size (0.110") | Termination Style | Must Release Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Dinkle Corporation, USA | 4.43 kOhms | Lighted Indicator | 7.6 mA | 96 V | 2 2 Form C C DPDT Form | 120 V | 20 ms | 20 ms | Non Latching | General Purpose | Socketable | 250 VAC | 30 VDC | 5 A | Silver Tin Oxide (AgSnO) | -40 °C | 55 °C | 0.11 in | Plug In Quick Connect | 36 VDC |
 Dinkle Corporation, USA | 1.1 kOhms | Lighted Indicator | 21.8 mA | 18 VDC | 2 2 Form C C DPDT Form | 24 VDC | 20 ms | 20 ms | Non Latching | General Purpose | Socketable | 250 VAC | 30 VDC | 5 A | Silver Tin Oxide (AgSnO) | -40 °C | 55 °C | 0.11 in | Plug In Quick Connect | 2.4 V |
