MD801-007 Series

Manufacturer: Cinch Connectivity Solutions

Catalog

MINIATURE D38999 CIRCULAR CONNEC

Part	Number of Positions	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Mounting Type	Orientation	Ingress Protection	Connector Type	Termination	Shielding	Applications	Shell Material	Current Rating (Amps)	Shell Finish	Color	Features	Cable Opening	Cable Opening	Primary Material	Shell Size - Insert
Cinch Connectivity Solutions MD801-007-16NF9-19SA	19	Threaded	-65 ░C	175 °C	9	19	Free Hanging (In-Line)	A	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut
Cinch Connectivity Solutions MD801-007-16M13-3PB		Threaded	-65 ░C	175 °C			Free Hanging (In-Line)	B	IP67 - Dust Tight Waterproof	Plug Male Pins	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Electroless Nickel	Silver	Coupling Nut	16.5 mm	0.65 in	Metal	13-3
Cinch Connectivity Solutions MD801-007-16NF13-37SC	37	Threaded	-65 ░C	175 °C	13	37	Free Hanging (In-Line)	C	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut
Cinch Connectivity Solutions MD801-007-16M8-13PB	13	Threaded	-65 ░C	175 °C	8	13	Free Hanging (In-Line)	B	IP67 - Dust Tight Waterproof	Plug Male Pins	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Electroless Nickel	Silver	Coupling Nut
Cinch Connectivity Solutions MD801-007-16NF6-4SE	4	Threaded	-65 ░C	175 °C			Free Hanging (In-Line)	E	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut	7.37 mm	0.29 in	Metal	6-4
Cinch Connectivity Solutions MD801-007-16NF13-3SB		Threaded	-65 ░C	175 °C			Free Hanging (In-Line)	B	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut	16.5 mm	0.65 in	Metal	13-3
Cinch Connectivity Solutions MD801-007-16M6-7PF	7	Threaded	-65 ░C	175 °C	6	7	Free Hanging (In-Line)	F	IP67 - Dust Tight Waterproof	Plug Male Pins	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Electroless Nickel	Silver	Coupling Nut
Cinch Connectivity Solutions MD801-007-16NF13-3SC		Threaded	-65 ░C	175 °C			Free Hanging (In-Line)	C	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut	16.5 mm	0.65 in	Metal	13-3
Cinch Connectivity Solutions MD801-007-16NF10-26SE	26	Threaded	-65 ░C	175 °C	10	26	Free Hanging (In-Line)	E	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Olive Drab Chromate over Cadmium	Olive Drab	Coupling Nut
Cinch Connectivity Solutions MD801-007-16M13-3SA		Threaded	-65 ░C	175 °C			Free Hanging (In-Line)	A	IP67 - Dust Tight Waterproof	Plug Female Sockets	Crimp	Shielded	Aerospace Military	Aluminum	5 A	Electroless Nickel	Silver	Coupling Nut	16.5 mm	0.65 in	Metal	13-3
