851-99 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN RCPT 25P 0.05 TIN-LEAD PCB
| Part | Contact Shape | Contact Material | Insulation Material | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Insulation Height [z] | Insulation Height [z] | Contact Length - Post | Contact Length - Post | Fastening Type | Contact Finish - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Mounting Type | Contact Finish - Mating | Termination | Insulation Color | Number of Rows | Connector Type | Contact Type | Number of Positions | Insulation Height | Insulation Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.185 in | 4.7 mm | 0.115 in | 2.92 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 25 | ||
 Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Surface Mount | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 44 | 5.25 mm | 0.207 in | ||||
Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.185 in | 4.7 mm | 0.115 in | 2.92 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 50 | ||
 Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.161 in | 4.1 mm | 0.099 in | 2.51 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 6 | ||
 Mill-Max Manufacturing Corp. | Circular | Brass Alloy | Nylon 4/6 Polyamide (PA46) | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.149 in | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | Surface Mount | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 28 | 3.78 mm | ||||||||
Mill-Max Manufacturing Corp. | Circular | Brass Alloy | Nylon 4/6 Polyamide (PA46) | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.149 in | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | Surface Mount | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 40 | 3.78 mm | ||||||||
Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.185 in | 4.7 mm | 0.115 in | 2.92 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 74 | ||
Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.161 in | 4.1 mm | 0.099 in | 2.51 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 23 | ||
Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | 0.185 in | 4.7 mm | 0.115 in | 2.92 mm | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Through Hole | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 62 | ||
Mill-Max Manufacturing Corp. | Circular | Beryllium Copper | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | 1.27 mm | 0.05 in | All | Push-Pull | Tin-Lead | 100 çin | 2.54 çm | 3 A | -55 C | 125 °C | UL94 V-0 | Surface Mount | Tin-Lead | Solder | Black | 1 | Receptacle | Female Socket | 25 | 5.25 mm | 0.207 in |
