737-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 13POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Number of Positions | Termination | Read Out | Gender | Pitch | Pitch | Number of Rows | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Color | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit Wire Wrap | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit Wire Wrap | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit Wire Wrap | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit Wire Wrap | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | 13 | Press-Fit Wire Wrap | Single | Female | 3.96 mm | 0.156 in | 1 | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 30 Áin | 0.76 Ám | Through Hole | Gold |
