VGS-150 Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 12V 150W
| Part | Features | Voltage - Output 1 | Approval Agency | Number of Outputs | Mounting Type | Type | Applications | Efficiency | Power (Watts) | Standard Number | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Isolation | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Adjustable Output Universal Input | 12 V | CE cURus | 1 | Chassis Mount | Conformal Coated Enclosed | Household Appliances ITE (Commercial) | 86 % | 150 W | 60335-1 62368-1 | 264 VAC 373 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 12.5 A |
CUI Inc. | Adjustable Output | 48 V | CB Scheme EN FCC IEC SIQ TUV UL | 1 | Chassis Mount | Enclosed | ITE (Commercial) | 88 % | 154 W | 55024 55032 Class B 60950-1 61000-3-2 61000-3-3 | 132 VAC 264 VAC | 88 VAC 176 VAC | 1.5 kV | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -20 °C | 70 °C | 3.2 A |
 CUI Inc. | Adjustable Output | 12 V | CB Scheme EN FCC IEC SIQ TUV UL | 1 | Chassis Mount | Enclosed | ITE (Commercial) | 86 % | 150 W | 55024 55032 Class B 60950-1 61000-3-2 61000-3-3 | 132 VAC 264 VAC | 88 VAC 176 VAC | 1.5 kV | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -20 °C | 70 °C | 12.5 A |
 CUI Inc. | 48 V | CE cURus | 1 | Chassis Mount | Enclosed | Household Appliances ITE (Commercial) | 89 % | 158 W | 60335-1 62368-1 | 305 VAC 431 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 3.3 A | |
 CUI Inc. | 48 V | CE cURus | 1 | Chassis Mount | Conformal Coated Enclosed | Household Appliances ITE (Commercial) | 89 % | 150 W | 60335-1 62368-1 | 305 VAC 431 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 3.3 A | |
CUI Inc. | Adjustable Output Universal Input | 12 V | CE cURus | 1 | Chassis Mount | Enclosed | Household Appliances ITE (Commercial) | 86 % | 150 W | 60335-1 62368-1 | 264 VAC 373 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 12.5 A |
CUI Inc. | Adjustable Output | 24 V | CB Scheme EN FCC IEC SIQ TUV UL | 1 | Chassis Mount | Enclosed | ITE (Commercial) | 88 % | 156 W | 55024 55032 Class B 60950-1 61000-3-2 61000-3-3 | 132 VAC 264 VAC | 88 VAC 176 VAC | 1.5 kV | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -20 °C | 70 °C | |
CUI Inc. | 12 V | CE cURus | 1 | Chassis Mount | Enclosed | Household Appliances ITE (Commercial) | 86 % | 150 W | 60335-1 62368-1 | 305 VAC 431 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 12.5 A | |
 CUI Inc. | Adjustable Output Universal Input | 24 V | CE cURus | 1 | Chassis Mount | Enclosed | Household Appliances ITE (Commercial) | 88 % | 156 W | 60335-1 62368-1 | 264 VAC 373 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | |
CUI Inc. | Adjustable Output Universal Input | 15 V | CE cURus | 1 | Chassis Mount | Enclosed | Household Appliances ITE (Commercial) | 87 % | 150 W | 60335-1 62368-1 | 264 VAC 373 VDC | 85 VAC 120 VDC | 4000 V | 6.26 in | 1.18 in | 97 mm | 3.82 in | 30 mm | 159 mm | -30 °C | 70 °C | 10 A |
