S18DL Series

Catalog

S18 DAYLIGHT VISIBLE EZ-LIGHT - 18 MM - IP67

Part	Lamp Color	Ingress Protection	Current	Type	Lens Style	Ratings	Voltage [Max]	Voltage [Min]	Lens Size [diameter]	Panel Cutout Shape	Millicandela Rating	Termination Style	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [x]	Lens Transparency	Millicandela Rating [custom]	Millicandela Rating [custom]	Panel Cutout Dimensions	Panel Cutout Dimensions	Wavelength - Peak	Wavelength - Peak
BANNER ENGINEERING S18DLRXXP	Red	IP67 IP69K	25 mA	LED	Round with Flat Top	DC	30 V	10 V	16 mm
BANNER ENGINEERING S18DLGXXPT	Green	IP67 IP69K NEMA 4X	25 mA	LED	Round with Flat Top	DC	30 V	10 V		Round	2.3 mcd	Screw Terminal	0.71 in	18 mm	Clear
BANNER ENGINEERING S18DLGRXPQ	Green Red	IP67 IP69K NEMA 4X	25 mA	LED	Round with Flat Top	DC	30 V	10 V		Round		Quick Connect			Diffused	2.3 mcd	1.4 mcd	18 mm	0.709 in
BANNER ENGINEERING S18DLGRYPQ	Green Red Yellow	IP67 IP69K NEMA 4X	25 mA	LED	Round with Flat Top	DC	30 V	10 V		Round	1.2 mcd 1.4 mcd 2.3 mcd	Quick Connect			Diffused			18 mm	0.709 in
BANNER ENGINEERING S18DLOXXPQ	Orange	IP67 IP69K	25 mA	LED	Round with Flat Top	DC	30 V	10 V	16 mm											608 nm
BANNER ENGINEERING S18DLGRYPT	Green Red Yellow	IP67 IP69K NEMA 4X	25 mA	LED	Round with Flat Top	DC	30 V	10 V		Round	1.2 mcd 1.4 mcd 2.3 mcd	Screw Terminal	0.71 in	18 mm	Clear
BANNER ENGINEERING S18DLWXXPT	White	IP67 IP69K	25 mA	LED	Round with Flat Top	DC	30 V	10 V	16 mm			Screw Terminal
BANNER ENGINEERING S18DLRBWPT	Blue Red White	IP67 IP69K	25 mA	LED	Round with Flat Top	DC	30 V	10 V	16 mm			Screw Terminal									470nm Blue 625nm Red
BANNER ENGINEERING S18DLGRYP	Green Red Yellow	IP67 IP69K NEMA 4X	25 mA	LED	Round with Flat Top	DC	30 V	10 V		Round	1.2 mcd 1.4 mcd 2.3 mcd	Wire Leads			Diffused			18 mm	0.709 in
BANNER ENGINEERING S18DLWXXP	White	IP67 IP69K	25 mA	LED	Round with Flat Top	DC	30 V	10 V	16 mm
