7520-0 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RECEPT PIN .022-.034".236"L

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish	Socket Depth	Socket Depth	Accepts Square Pin Size	Accepts Square Pin Size	Flange Diameter [diameter]	Flange Diameter [diameter]	Termination	Length - Overall [x]	Length - Overall [x]	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Tail Type	Accepts Pin Diameter [Max] [diameter]	Accepts Pin Diameter [Max] [diameter]	Accepts Pin Diameter [Min] [diameter]	Accepts Pin Diameter [Min] [diameter]	Contact Material	Contact Finish Thickness	Contact Finish Thickness	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]
Mill-Max Manufacturing Corp. 7520-0-15-01-16-27-10-0	-55 C	125 °C	Gold	0.147 in	3.73 mm	0.025 in	0.64 mm	2.18 mm	0.086 in	Press-Fit	0.236 in	6 mm	0.051 in	1.3 mm	Turret	0.86 mm	0.034 "	0.022 "	0.56 mm	Beryllium Copper	30 Áin	0.76 Ám	0.066 in	1.68 mm
Mill-Max Manufacturing Corp. 7520-0-15-80-16-14-10-0	-55 C	125 °C	Gold	0.147 in	3.73 mm	0.025 in	0.64 mm	2.18 mm	0.086 in	Press-Fit	0.236 in	6 mm	0.051 in	1.3 mm	Turret	0.86 mm	0.034 "	0.022 "	0.56 mm	Beryllium Copper	10 Áin	0.25 Ám	0.066 in	1.68 mm
Mill-Max Manufacturing Corp. 7520-0-15-80-16-27-10-0	-55 C	125 °C	Gold	0.147 in	3.73 mm	0.025 in	0.64 mm	2.18 mm	0.086 in	Press-Fit	0.236 in	6 mm	0.051 in	1.3 mm	Turret	0.86 mm	0.034 "	0.022 "	0.56 mm	Beryllium Copper	30 Áin	0.76 Ám	0.066 in	1.68 mm
Mill-Max Manufacturing Corp. 7520-0-15-15-16-27-10-0	-55 C	125 °C	Gold	0.147 in	3.73 mm	0.025 in	0.64 mm	2.18 mm	0.086 in	Press-Fit	0.236 in	6 mm	0.051 in	1.3 mm	Turret	0.86 mm	0.034 "	0.022 "	0.56 mm	Beryllium Copper	30 Áin	0.76 Ám	0.066 in	1.68 mm
Mill-Max Manufacturing Corp. 7520-0-15-01-16-14-10-0	-55 C	125 °C	Gold	0.147 in	3.73 mm	0.025 in	0.64 mm	2.18 mm	0.086 in	Press-Fit	0.236 in	6 mm	0.051 in	1.3 mm	Turret	0.86 mm	0.034 "	0.022 "	0.56 mm	Beryllium Copper	10 Áin	0.25 Ám	0.066 in	1.68 mm
