Rack Mount Power Supplies
Rack Mount Power Supplies
| Part | Voltage - Input [Max] | Voltage - Input [Min] | Applications | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Number of Outputs | Approval Agency | Efficiency | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Power (Watts) | Type | Current - Output 1 | Features | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 265 VAC | 85 VAC | ITE (Commercial) | Chassis Mount | 70 °C | -10 °C | 12 V | 1 | CE | 92 % | 13.54 in | 344 mm | 107 mm | 40.8 mm | 4.21 in | 1.6 " | 2500 W | Enclosed | 200 A | Adjustable Output Load Sharing PFC Remote On/Off Remote Sense Standby Output Universal Input | 3000 V |
 TDK Corporation | 265 VAC | 85 VAC | ITE (Commercial) | Chassis Mount | 70 °C | -10 °C | 48 V | 1 | CE | 93 % | 13.54 in | 344 mm | 107 mm | 40.8 mm | 4.21 in | 1.6 " | 2500 W | Enclosed | 52 A | Adjustable Output I2C Interface Load Sharing PMBus™ Remote On/Off Remote Sense Standby Output Universal Input | 3000 V |
TDK Corporation | 265 VAC | 85 VAC | ITE (Commercial) | Chassis Mount | 70 °C | -10 °C | 24 V | 1 | CE | 92 % | 13.54 in | 344 mm | 107 mm | 40.8 mm | 4.21 in | 1.6 " | 2500 W | Enclosed | 96 A | Adjustable Output I2C Interface Load Sharing PMBus™ Remote On/Off Remote Sense Standby Output Universal Input | 3000 V |
