D Series

Catalog

CERAMIC DISC CAPACITORS D 500V 15PF +/-5% U2J BULK E3

...

Part	Capacitance	Mounting Type	Tolerance	Operating Temperature (Max)	Operating Temperature (Min)	Temperature Coefficient	Lead Style	Lead Spacing	Size / Dimension Diameter	Voltage - Rated	Package / Case	Applications	Tolerance (Negative)	Tolerance (Positive)
Vishay Dale D150J20U2JL63L6R	15 pF	Through Hole	5 %	125 °C	-55 °C	U2J	Straight	0.252 in	0.197 in	500 V	Disc Radial	General Purpose
Vishay Dale D122Z20Y5VH6TJ5R	1200 pF	Through Hole		85 °C	-30 °C	Y5V (F)	Formed Leads - Kinked	0.197 in	0.197 in	100 VAC/DC	Disc Radial	General Purpose	20 %	80 %
Vishay Dale D101G29U2JH65L2R	100 pF	Through Hole	2 %	125 °C	-55 °C	U2J	Straight	0.098 in	0.295 in	100 VAC/DC	Disc Radial	General Purpose
Vishay Dale D122Z20Z5UH6UJ5R	1200 pF	Through Hole		125 °C	-30 °C	Z5U	Formed Leads - Kinked	0.197 in	0.197 in	100 VAC/DC	Disc Radial	General Purpose	20 %	80 %
Vishay Dale D682M25Z5UF6UJ5R	6800 pF	Through Hole	20 %	125 °C	-30 °C	Z5U	Formed Leads - Kinked	0.197 in	0.256 in	50 V	Disc Radial	General Purpose
Vishay Dale D221K20Y5PH6UJ5R	220 pF	Through Hole	10 %	125 °C	-30 °C	Y5P (B)	Formed Leads - Kinked	0.197 in	0.197 in	100 VAC/DC	Disc Radial	General Purpose
Vishay Dale D560J20SL0F6TJ5R	56 pF	Through Hole	5 %	125 °C	-55 °C	SL	Formed Leads - Kinked	0.197 in	0.197 in	50 V	Disc Radial	General Purpose
Vishay Dale D681K25X5FL63L6R	680 pF	Through Hole	10 %	85 °C	-55 °C	X5F	Straight	0.252 in	0.256 in	500 V	Disc Radial	General Purpose
Vishay Dale D183M39Z5UH65L2R	0.018 µF	Through Hole	20 %	125 °C	-30 °C	Z5U	Straight	0.098 in	0.394 in	100 VAC/DC	Disc Radial	General Purpose
Vishay Dale D181G39U2JH65J5R	180 pF	Through Hole	2 %	125 °C	-55 °C	U2J	Formed Leads - Kinked	0.197 in	0.394 in	100 VAC/DC	Disc Radial	General Purpose
