R2E220 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
220 MM AC CENTRIFUGAL FAN
| Part | Material - Blade | Air Flow | Air Flow | Size / Dimension [diameter] | Size / Dimension | Width | Bearing Type | Fan Type | Power (Watts) | Ingress Protection | RPM | Termination | Voltage - Rated | Approval Agency | Weight [custom] | Weight [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Features | Voltage Range [Min] | Voltage Range [Max] | Air Flow | Operating Temperature | Weight [custom] | Weight [custom] | Width [y] | Weight | Weight | Noise | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 15.16 mł/min | 541.5 CFM | 220 mm | Round | 71 mm | Ball | Motorized Impellers | 107 W | IP44 | 2050 RPM | 4 Wire Leads | 230 VAC | UL | 2.9 lbs | 1.3 kg | -25 °C | 60 °C | |||||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 221.4 mm | Round | 71 mm | Ball | Motorized Impellers | 90 W | IP44 | 2700 RPM | 3 Wire Leads with Splice Terminals 4 Wire Leads with Splice Terminals | 230 VAC | CCC CE CSA EAC UL | -25 °C | 40 °C | 400 mA | -25 °C | 40 °C | Capacitor Thermal Overload Protector (TOP) | |||||||||||||||
ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 14.83 m³/min | 220 mm | Round | 71 mm | Ball | Motorized Impellers | 108 W | IP44 | 2100 RPM | 4 Wire Leads | 115 VAC | UL | 2.9 lbs | 1.3 kg | -25 °C | 60 °C | 100 VAC | 130 VAC | 529.7 CFM | |||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 252 mm | Round | 71 mm | Ball | Motorized Impellers | 90 W | IP44 | 2700 RPM | 4 Wire Leads | 230 VAC | CCC CE CSA UL | 400 mA | Capacitor Thermal Overload Protection (TOP) | 131 °F | 3.2 lbs | 1.5 kg | ||||||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 221.4 mm | Round | 71 mm | Ball | Motorized Impellers | 100 W | IP44 | 2750 RPM | 4 Wire Leads with Splice Terminals | 415 VAC | CCC CE EAC | -25 °C | 55 °C | 0.25 A | Capacitor Thermal Overload Protector (TOP) | |||||||||||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon | 220 mm | Round | Ball | Motorized Impellers | 135 W | IP44 | 2650 RPM | 4 Wire Leads with Splice Terminals | 230 VAC | CCC CE EAC | -25 °C | 75 ░C | 600 mA | Capacitor Thermal Overload Protector (TOP) | 73.5 mm | |||||||||||||||||
 ebm-papst Inc. | Nylon 6 Polyamide (PA6) | 14.84 mł/min | 530 CFM | 220 mm | Round | 71 mm | Ball | Motorized Impellers | 90 W | IP44 | 2700 RPM | 4 Wire Leads with Splice Terminals | 230 VAC | CCC CE CSA | 400 mA | Capacitor Thermal Overload Protector (TOP) | 131 °F | 3.1 lbs | 1.4 kg | 74 dB(A) | 55 °C | ||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 220 mm | Round | 71 mm | Ball | Motorized Impellers | 90 W | IP44 | 2700 RPM | 4 Wire Leads with Splice Terminals | 230 VAC | CCC CE EAC | -25 °C | 40 °C | 400 mA | -25 °C | 40 °C | Capacitor Thermal Overload Protector (TOP) | |||||||||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon | 14.84 mł/min | 530 CFM | 220 mm | Round | 71 mm | Ball | Motorized Impellers | 100 W | 2550 RPM | 4 Wire Leads | 230 VAC | CCC CE CSA UL | 2.9 lbs | 1.3 kg | 74 dB(A) |
