CPFE1000 Series
Manufacturer: TDK Corporation
Beta
⌘K
AC/DC OPEN FRAME POWER SUPPLY (PSU), ITE, 1 OUTPUT, 720 W, 90V AC TO 265V AC, ADJUSTABLE, FIXED
| Part | Current - Output 1 | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Voltage - Input [Max] | Voltage - Input [Min] | Approval Agency | Applications | Voltage - Isolation | Mounting Type | Power (Watts) | Type | Number of Outputs | Efficiency | Features | Voltage - Output 1 | Minimum Load Required | Size / Dimension [z] | Size / Dimension [y] | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 60 A | 112 mm | 44 mm | 4.41 " | 254 mm | 1.73 " | 10 in | 265 VAC | 85 VAC | CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 720 W | Open Frame Conformal Coated | 1 | 81 % | Adjustable Output Baseplate I2C Interface Remote On/Off Remote Sense Universal Input | 12 V | |||||
 TDK Corporation | 36 A | 112 mm | 44 mm | 4.41 " | 254 mm | 1.73 " | 10 in | 265 VAC | 85 VAC | CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1.008 kW | Conformal Coated Enclosed | 1 | 86 % | Adjustable Output Baseplate I2C Interface Remote On/Off Remote Sense Universal Input | 28 V | |||||
 TDK Corporation | 36 A | 4.21 in | 254 mm | 1.57 " | 10 in | 265 VAC | 90 VAC | CB CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1 kW | Open Frame | 1 | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 28 V | 40 mm | 107 mm | -40 °C | 85 °C | ||||
 TDK Corporation | 21 A | 4.21 in | 254 mm | 1.57 " | 10 in | 265 VAC | 90 VAC | CB CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1 kW | Open Frame | 1 | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 48 V | 40 mm | 107 mm | -40 °C | 85 °C | ||||
TDK Corporation | 36 A | 112 mm | 44 mm | 4.41 " | 254 mm | 1.73 " | 10 in | 265 VAC | 85 VAC | CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1.008 kW | Open Frame Conformal Coated | 1 | 86 % | Adjustable Output Baseplate I2C Interface Remote On/Off Remote Sense Universal Input | 28 V | |||||
TDK Corporation | 60 A | 4.41 " | 254 mm | 1.69 in | 10 in | 265 VAC | 90 VAC | CB CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 720 W | Enclosed | 1 | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 12 V | 43 mm | 112 mm | -40 °C | 85 °C | ||||
 TDK Corporation | 36 A | 7.48 in | 270 mm | 2.4 in | 10.63 " | 265 VAC | 90 VAC | CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 720 W | Enclosed | 1 | 81 % | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 28 V | 61 mm | 190 mm | -40 °C | 85 °C | |||
TDK Corporation | 21 A | 7.48 in | 270 mm | 2.4 in | 10.63 " | 265 VAC | 90 VAC | CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 720 W | Enclosed | 1 | 81 % | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 48 V | 61 mm | 190 mm | -40 °C | 85 °C | |||
TDK Corporation | 21 A | 4.41 " | 254 mm | 1.69 in | 10 in | 265 VAC | 90 VAC | CB CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1 kW | Enclosed | 1 | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 48 V | 43 mm | 112 mm | -40 °C | 85 °C | ||||
TDK Corporation | 21 A | 4.41 " | 254 mm | 1.69 in | 10 in | 265 VAC | 90 VAC | CB CE | ITE (Commercial) | 4.242 kV | Chassis Mount | 1 kW | Open Frame | 1 | Adjustable Output Baseplate I2C Interface Load Sharing Remote On/Off Remote Sense Standby Output Universal Input | 48 V | 43 mm | 112 mm | -40 °C | 85 °C |
