RPM21 Series
Manufacturer: SCHNEIDER ELECTRIC
Beta
⌘K
POWER RELAY, DPDT, 24 VDC, 15 A, ZELIO RPM SERIES, SOCKET
| Part | Coil Resistance | Mounting Type | Must Release Voltage | Features | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Must Operate Voltage | Coil Voltage | Switching Voltage [Max] | Operate Time | Termination Style | Relay Type | Release Time | Approval Agency | Contact Form | Load - Max Switching | Coil Current | Contact Material | Contact Rating (Current) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHNEIDER ELECTRIC | 640 Ohms | Socketable | 2.4 VDC | Lighted Indicator | 55 °C | -40 C | Non Latching | 19.2 VDC | 24 VDC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 0.0375 A | Silver Nickel (AgNi) | 15 A |
SCHNEIDER ELECTRIC | 4.43 kOhms | Socketable | 18 VAC | Lighted Indicator | 55 °C | -40 C | Non Latching | 96 VAC | 120 VAC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 27.1 mA | Silver Nickel (AgNi) | 15 A |
 SCHNEIDER ELECTRIC | 2560 Ohms | Socketable | 4.8 VDC | Test Button | 55 °C | -40 C | Non Latching | 38.4 VDC | 48 VDC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 18.8 mA | Silver Nickel (AgNi) | 15 A |
 SCHNEIDER ELECTRIC | 16.27 kOhms | Socketable | 34.5 VAC | Lighted Indicator | 55 °C | -40 C | Non Latching | 184 VAC | 230 VAC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 14.1 mA | Silver Nickel (AgNi) | 15 A |
SCHNEIDER ELECTRIC | 177 Ohms | Socketable | 3.6 VAC | Lighted Indicator | 55 °C | -40 C | Non Latching | 19.2 VAC | 24 VAC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 135.6 mA | Silver Nickel (AgNi) | 15 A |
SCHNEIDER ELECTRIC | 160 Ohms | Socketable | 1.2 VDC | Lighted Indicator | 55 °C | -40 C | Non Latching | 9.6 VDC | 12 VDC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 0.075 A | Silver Nickel (AgNi) | 15 A |
SCHNEIDER ELECTRIC | 708 Ohms | Socketable | 7.2 VAC | Test Button | 55 °C | -40 C | Non Latching | 38.4 VAC | 48 VAC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 67.8 mA | Silver Nickel (AgNi) | 15 A |
SCHNEIDER ELECTRIC | 13.44 kOhms | Socketable | 11 VDC | Test Button | 55 °C | -40 C | Non Latching | 88 VDC | 110 VDC | 28 VDC 250 VAC | 20 ms | Plug In | General Purpose | 20 ms | CSA EAC UL | DPDT (2 Form C) | 420 W 3750 VA | 8.2 mA | Silver Nickel (AgNi) | 15 A |
