325-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 48POS 0.100
| Part | Material - Insulation | Termination Rows | Card Thickness | Card Thickness | Contact Finish | Gender | Mounting Type | Pitch | Pitch | Number of Rows | Color | Number of Positions/Bay/Row | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Read Out | Termination | Number of Positions | Card Type | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | 1 | Green | 48 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Single | Solder Eyelet(s) | 48 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | Green | 24 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Dual | Solder | 48 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | 2 | Flush Mount M3 Threaded Insert Top Opening | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | Green | 24 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Dual | Solder Eyelet(s) | 48 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | 2 | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | Green | 24 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Dual | Solder Eyelet(s) | 48 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | 1 | Green | 48 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Single | Solder Eyelet(s) | 48 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | 1 | Green | 48 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Single | Wire Wrap | 48 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | Green | 24 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Dual | Solder | 48 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | 2 | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | 1 | Green | 48 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Single | Wire Wrap | 48 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | Green | 24 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Dual | Solder Eyelet(s) | 48 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 2 | 2 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | Gold | Female | Through Hole | 0.1 " | 2.54 mm | 1 | Green | 48 | Cantilever | -65 ░C | 125 °C | Copper Alloy | Single | Solder | 48 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening |
