ABC150 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
AC/DC CONVERTER 24V 110/150W
| Part | Minimum Load Required | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Applications | Number of Outputs | Operating Temperature [Max] | Operating Temperature [Min] | Features | Type | Power (Watts) | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Isolation | Mounting Type | Efficiency | Voltage - Output 1 | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 24 V | 4.17 A | |
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 24 V | 4.17 A | |
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 12 V | 8.33 A | |
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 5 V | 16 A | |
Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 15 V | 6.67 A | |
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 12 V | 8.33 A | |
Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 48 V | 2.08 A | |
 Bel Fuse Inc. | 101.6 mm | 33.6 mm | 4 " | 50.8 mm | 2 in | 1.32 in | ITE (Commercial) | 1 | 70 °C | -20 °C | Adjustable Output DC Input Capable Standby Output Universal Input | Open Frame | 110 W 150 W | CE | 264 VAC | 90 VAC | 4.242 kV | Chassis Mount | 86 % | 5 V | 16 A |
