F6 Series

Catalog

SIGNAL CONDITIONING 963-FSSCSR1T2G35P2BH RPLCMT PN

Part	Applications	Insertion Loss	Height (Max) [Max] [z]	Height (Max) [Max] [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Mounting Type	Frequency - Center	Bandwidth	Size / Dimension [Max]	Size / Dimension [Max]	Size / Dimension [Min]	Size / Dimension [Min]	Height (Max) [z]	Height (Max) [z]
Taiyo Yuden F6QB2G350P2BH-J	General Purpose	2.8 dB	0.02 in	0.5 mm	0.043 in	0.035 "	1.1 mm	0.9 mm	5-SMD No Lead	Surface Mount
Taiyo Yuden F6KA2G605A4LA-Z	LTE SCDMA	2.4 dB	0.02 in	0.5 mm	0.055 "	0.039 in	1.4 mm	1 mm	5-SMD No Lead	Surface Mount	2.605 GHz	100 MHz
Taiyo Yuden F6QG2G655P2KE-J
Taiyo Yuden F6QP2G017R2SF-J	LTE SCDMA	1.3 dB	0.02 in	0.5 mm					5-SMD No Lead	Surface Mount	2.017 GHz		1.1 mm	0.043 in	0.035 in	0.9 mm
Taiyo Yuden F6FC2G441H4PE-J	Bluetooth WLAN	1 dB			0.043 in	0.035 "	1.1 mm	0.9 mm	5-SMD No Lead	Surface Mount							0.44 mm	0.017 in
Taiyo Yuden F6QA1G585M2AT-J	GPS	1.2 dB	0.02 in	0.5 mm	0.043 in	0.035 "	1.1 mm	0.9 mm	5-SMD No Lead	Surface Mount	1.585 GHz	40 MHz
Taiyo Yuden F6QA1G581M2QZ-J	GPS	1.4 dB	0.02 in	0.5 mm	0.043 in	0.035 "	1.1 mm	0.9 mm	5-SMD No Lead	Surface Mount	1581 MHz
Taiyo Yuden F6QA1G747M2QS-J	General Purpose	2.1 dB	0.02 in	0.5 mm	0.043 in	0.035 "	1.1 mm	0.9 mm	5-SMD No Lead	Surface Mount
