XB3-24 Series
Manufacturer: Digi International
Beta
⌘K
802.15.4 SOC 2400MHZ 1000KBPS 34-PIN SMD MODULE
| Part | Frequency | Data Rate | Serial Interfaces | Modulation | Package / Case | Power - Output | Current - Receiving | Mounting Type | Sensitivity | Memory Size | Antenna Type | Operating Temperature [Max] | Operating Temperature [Min] | Current - Transmitting | Voltage - Supply [Max] | Voltage - Supply [Min] | RF Family/Standard | Protocol | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 8 dBm | 17 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Chip Integrated | 85 °C | -40 C | 135 mA | 3.6 V | 2.1 V | 802.15.4 | Bluetooth v4.0 Zigbee® | |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 8 dBm | 15 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Antenna Not Included Castellation | 85 °C | -40 C | 40 mA | 3.6 V | 2.1 V | 802.15.4 | Bluetooth v4.0 Zigbee® | |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 8 dBm | 15 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Integrated Trace | 85 °C | -40 C | 40 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | Module | 8 dBm | 15 mA | Through Hole | -103 dBm | 1 MB 128 kB | Integrated Trace | 85 °C | -40 C | 40 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 37-SMD Module | 19 dBm | 15 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Integrated Trace | 85 °C | -40 C | 135 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | Module | 19 dBm | 15 mA | Through Hole | -103 dBm | 1 MB 128 kB | Integrated Trace | 85 °C | -40 C | 135 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | Module | 8 dBm | 15 mA | Through Hole | -103 dBm | 1 MB 128 kB | Antenna Not Included U.FL | 85 °C | -40 C | 40 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 19 dBm | 15 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Antenna Not Included U.FL | 85 °C | -40 C | 135 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 8 dBm | 15 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Antenna Not Included Castellation | 85 °C | -40 C | 40 mA | 3.6 V | 2.1 V | 802.15.4 | Zigbee® | EFR32MG |
 Digi International | 2.4 GHz | 250 KBd | I2C SPI UART | DSSS | 34-SMD Module | 19 dBm | 17 mA | Surface Mount | -103 dBm | 1 MB 128 kB | Antenna Not Included U.FL | 85 °C | -40 C | 135 mA | 3.6 V | 2.1 V | 802.15.4 | Bluetooth v4.0 Zigbee® |
