5308 Series

Catalog

CABLE GLAND 2.5-8MM PG9 POLYAMID

Part	Type	Panel Hole Size	Panel Hole Size	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Includes	Ingress Protection	Color	Thread Size	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Material	Thread Length	Thread Length	Operating Temperature [Max]	Operating Temperature [Min]	Panel Hole Size	Outside Cable Diameter (Max)	Operating Temperature [custom]	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min]
TE Connectivity Raychem Cable Protection 5308 509/SET	Cable Gland	0.598 in	15.2 mm	0.098 in	2.5 mm	Locknut	IP68 - Dust Tight Waterproof	Black	PG9	8 mm	0.315 in	Polyamide (PA) Nylon	8 mm	0.315 in	100 °C	-40 °C
Altech Corporation 5308 509/SET	Cable Gland	0.598 in	15.2 mm	0.098 in	2.5 mm	Locknut	IP68 - Dust Tight Waterproof	Black	PG9	8 mm	0.315 in	Polyamide (PA) Nylon	8 mm	0.315 in	100 °C	-40 °C
TE Connectivity Raychem Cable Protection 5308 529/SET	Cable Gland		1.457 in	0.551 in	14 mm	Locknut	IP68 - Dust Tight Waterproof	Black	PG29		0.984 in	Polyamide (PA) Nylon	11 mm	0.433 in	100 °C	-40 °C	37 mm	25 mm
Altech Corporation 5308 529/SET	Cable Gland		1.457 in	0.551 in	14 mm	Locknut	IP68 - Dust Tight Waterproof	Black	PG29		0.984 in	Polyamide (PA) Nylon	11 mm	0.433 in	100 °C	-40 °C	37 mm	25 mm
TE Connectivity Raychem Cable Protection 5308 953/SET	Cable Gland	0.984 in	25 mm	0.354 in	9 mm	Locknut	IP68 - Dust Tight Waterproof	Gray	M25x1.5	18.01 mm	0.709 in	Polyamide (PA) Nylon	10 mm	0.394 in					-25 °C 100 °C
Altech Corporation 5308 953/SET	Cable Gland	0.984 in	25 mm	0.354 in	9 mm	Locknut	IP68 - Dust Tight Waterproof	Gray	M25x1.5	18.01 mm	0.709 in	Polyamide (PA) Nylon	10 mm	0.394 in					-25 °C 100 °C
TE Connectivity Raychem Cable Protection 5308 943/SET	Cable Gland	0.984 in	25 mm	0.354 in	9 mm	Locknut	IP68 - Dust Tight Waterproof	Black	M25x1.5	18.01 mm	0.709 in		10 mm	0.394 in	100 °C	-40 °C
Altech Corporation 5308 943/SET	Cable Gland	0.984 in	25 mm	0.354 in	9 mm	Locknut	IP68 - Dust Tight Waterproof	Black	M25x1.5	18.01 mm	0.709 in		10 mm	0.394 in	100 °C	-40 °C
TE Connectivity Raychem Cable Protection 5308 921	Cable Gland	0.835 in	21.2 mm				IP68 - Dust Tight Waterproof	Black	1/2" NPT	12 mm	0.472 in	Polyamide (PA) Nylon	14 mm	0.551 in	100 °C	-40 °C				5 mm	0.197 in
Altech Corporation 5308 921	Cable Gland	0.835 in	21.2 mm				IP68 - Dust Tight Waterproof	Black	1/2" NPT	12 mm	0.472 in	Polyamide (PA) Nylon	14 mm	0.551 in	100 °C	-40 °C				5 mm	0.197 in
