807-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Pitch | Pitch | Gender | Contact Finish | Read Out | Termination Rows | Mounting Type | Contact Material | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Material - Insulation | Number of Positions | Termination | Color | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Gold | Dual | 1 | Through Hole | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 58 | Solder | Green | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 29 | |
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Gold | Single | 1 | Right Angle Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Solder | Green | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 29 | 1 | |
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Gold | Single | 1 | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Solder | Green | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 29 | 1 | |
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Gold | Single | 1 | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Solder | Green | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | 29 | 1 | |||
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Tin | Dual | 1 | Right Angle Through Hole | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 58 | Solder | Green | Non Specified - Dual Edge | Semi Bellows | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 29 | |||
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Tin | Single | 1 | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Wire Wrap | Green | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 29 | 1 | |||
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Gold | Dual | 1 | Right Angle Through Hole | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 58 | Solder | Green | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 29 | |
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Tin | Single | 1 | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Solder Eyelet(s) | Green | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | 29 | 1 | |||||
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Tin | Single | 1 | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 29 | Wire Wrap | Green | Non Specified - Single Edge | Semi Bellows | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 29 | 1 | |||
 EDAC Inc. | 3.96 mm | 0.156 in | Female | Tin | Dual | 1 | Through Hole | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 58 | Wire Wrap | Green | Non Specified - Dual Edge | Semi Bellows | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 29 |
