Coupled Inductors IND DRAQ75 8.5uH SMT SHLD
Coupled Inductors IND DRAQ75 8.5uH SMT SHLD
| Part | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Shielding | Current Rating - Parallel | Mounting Type | Inductance - Connected In Parallel | DC Resistance (DCR) - Series [Max] | Current Rating - Series | Tolerance | Height [z] | Height [z] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Coils | DC Resistance (DCR) - Parallel | Package / Case | Inductance - Connected In Series | DC Resistance (DCR) - Series | DC Resistance (DCR) - Parallel [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 4.14 A | Surface Mount | 6.41 µH | 146 mOhm | 2.07 A | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 37 mOhm | Nonstandard | 24.95 µH | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 1.88 A | Surface Mount | 32.8 µH | 708 mOhm | 940 mA | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 177 mOhm | Nonstandard | 131.39 µH | ||
 Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 2.02 A | Surface Mount | 28.3 µH | 1.01 A | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 153 mOhm | Nonstandard | 106.6 µH | 610 mOhm | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 4.53 A | Surface Mount | 4.48 µH | 2.26 A | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 31 mOhm | Nonstandard | 17.93 µH | 122 mOhm | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 1.49 A | Surface Mount | 56.6 µH | 740 mA | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 283 mOhm | Nonstandard | 226.31 µH | 1.13 Ohm | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 3.57 A | Surface Mount | 8.47 µH | 196 mOhm | 1.79 A | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 49 mOhm | Nonstandard | 33.86 µH | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 1.14 A | Surface Mount | 98.3 µH | 570 mA | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 478 mOhm | Nonstandard | 393.23 µH | 1.91 Ohm | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 760 mA | Surface Mount | 217 µH | 380 mA | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 1.09 Ohm | Nonstandard | 866.26 µH | 4.36 Ohm | ||
Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 2.48 A | Surface Mount | 18.7 µH | 1.24 A | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | 102 mOhm | Nonstandard | 68.55 µH | 408 mOhm | ||
 Eaton - Electronics Division | 0.299 " | 7.6 mm | 7.6 mm | 0.299 " | Shielded | 1.39 A | Surface Mount | 68.3 µH | 690 mA | 25 % | 4.5 mm | 0.177 in | -40 C | 165 °C | 2 | Nonstandard | 273.21 µH | 1.3 Ohm | 324 mOhm |
