PDB18 Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 1K OHM 1/5W CARBON LINEAR
| Part | Number of Gangs | Actuator Type | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Mounting Type | Rotation | Number of Turns | Adjustment Type | Power (Watts) | Power (Watts) | Taper | Bushing Thread | Actuator Length [x] | Actuator Length [x] | Resistance (Ohms) | Termination Style | Tolerance | Built in Switch | Resistive Material | Size - Body [diameter] | Size - Body [diameter] | Resistance (Ohms) [custom] | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 1 | Knurled and Slotted | 6 mm | 0.236 in | Panel Mount | 300 ░ | 1 | Side Adjustment | 0.2 W | 0.2 W | Linear | M7 x 0.75 | 0.787 in | 20 mm | 1k | PC Pins | 20 % | None | Carbon | ||||
 Bourns Inc. | 1 | Knurled and Slotted | 6 mm | 0.236 in | Through Hole | 300 ░ | 1 | User Defined | 0.2 W | 0.2 W | Linear | M7 x 0.75 | 0.984 in | 25 mm | Solder Lug | 20 % | None | Carbon | 17 mm | 0.669 " | 50 kOhms | ||
 Bourns Inc. | 2 | Knurled and Slotted | 6 mm | 0.236 in | Through Hole | 300 ░ | 1 | Side Adjustment | 0.125 W | 0.125 W | Linear | M7 x 0.75 | 0.591 in | 15 mm | 10k | PC Pins | 20 % | None | Carbon | 17 mm | 0.669 " | ||
 Bourns Inc. | 1 | Flatted | 6 mm | 0.236 in | Panel Mount | 300 ░ | 1 | User Defined | 0.2 W | 0.2 W | Linear | M7 x 0.75 | 0.709 in | 18 mm | Solder Lug | 20 % | None | Carbon | 1 MΩ | ||||
 Bourns Inc. | 1 | Flatted | 6 mm | 0.236 in | Panel Mount | 300 ░ | 1 | User Defined | 0.1 W | 0.1 W | Logarithmic | M7 x 0.75 | 0.591 in | 15 mm | 100k | Solder Lug | 20 % | None | Carbon |
