PP75 Series
Manufacturer: Anderson Power Products, Inc.
Beta
⌘K
CONNECTOR HOUSING, GREEN, POWERPOLE PP75 SERIES, 1 POSITIONS
| Part | Note | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Voltage Rating | Material - Insulation | Fastening Type | Mounting Type | Number of Positions | Connector Type | Number of Rows | Color | Contact Termination | Contact Type | Features | For Use With/Related Products | Accessory Type | Type | Wire Gauge [Min] | Wire Gauge [Max] | Contact Material | Contact Finish | Wire Gauge | Termination | Connector Style | Specifications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Anderson Power Products, Inc. | Contacts Not Included | -20 ░C | 105 ░C | 120 A | 600 V | Polycarbonate (PC) | Spring Retention | Free Hanging (In-Line) | 1 | Non-Gendered | 1 | Green | Crimp | Non-Gendered | Stackable | |||||||||||
 Anderson Power Products, Inc. | SB® 120 Series | Nut | ||||||||||||||||||||||||
 Anderson Power Products, Inc. | Contacts Not Included | -20 ░C | 105 ░C | 120 A | 600 V | Polycarbonate (PC) | Spring Retention | Free Hanging (In-Line) | 1 | Non-Gendered | 1 | Red | Crimp | Non-Gendered | Stackable | |||||||||||
 Anderson Power Products, Inc. | Crimp | Non-Gendered | Machined | 10 AWG | 12 AWG | Copper Alloy | Tin | |||||||||||||||||||
 Anderson Power Products, Inc. | -20 ░C | 105 ░C | 600 V | Polycarbonate (PC) | Spring Retention | Free Hanging (In-Line) | 1 | Non-Gendered | 1 | Green | Stackable | Copper Alloy | Silver | 6 AWG | Crimp | Single Pole | ||||||||||
 Anderson Power Products, Inc. | Black | Powerpole® 75 Series | Grommet | 8 AWG | ||||||||||||||||||||||
 Anderson Power Products, Inc. | Contacts Not Included | -20 ░C | 105 ░C | 120 A | 600 V | Polycarbonate (PC) | Spring Retention | Free Hanging (In-Line) | 1 | Non-Gendered | 1 | Black | Crimp | Non-Gendered | Stackable | |||||||||||
 Anderson Power Products, Inc. | Contacts Not Included | -20 ░C | 105 ░C | 120 A | 600 V | Polycarbonate (PC) | Spring Retention | Free Hanging (In-Line) | 1 | Non-Gendered | 1 | White | Crimp | Non-Gendered | Stackable | |||||||||||
 Anderson Power Products, Inc. | Crimp | Non-Gendered | Machined | Copper Alloy | Silver | 6 AWG |
