DRL30 Series

Catalog

AC/DC POWER SUPPLY SINGLE-OUT 12V 2.1A 25.2W 4-PIN

Part	Efficiency	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Output 1	Number of Outputs	Power (Watts)	DC Voltage - Input (Max) [Max]	Voltage - Isolation	Current - Output (Max) [Max]	Features	Input Type	Applications	DC Voltage - Input (Min) [Min]	Approval Agency	AC Voltage - Input [Max]	AC Voltage - Input [Min]
TDK Corporation DRL30-12-1	88 %	-20 °C	71 °C	1.42 in	2.19 in	55.6 mm	3.58 in	90.9 mm	36.1 mm	12 V	1	30 Watts	373 V	3000 V	2.1 A	Adjustable Output Universal Input	AC or DC	Hazardous Locations ITE (Commercial)	120 V	CE	264 VAC	85 VAC
TDK Corporation DRL30-24-1	90 %	-20 °C	71 °C	1.42 in	2.19 in	55.6 mm	3.58 in	90.9 mm	36.1 mm	24 V	1	30 Watts	373 V	3000 V	1.25 A	Adjustable Output Universal Input	AC or DC	Hazardous Locations ITE (Commercial)	120 V	CE	264 VAC	85 VAC
