DRL60 Series

Catalog

AC/DC POWER SUPPLY SINGLE-OUT 24V 2.5A 60W

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Current - Output (Max) [Max]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Voltage - Output 1	Efficiency	Operating Temperature [Min]	Operating Temperature [Max]	DC Voltage - Input (Max) [Max]	Input Type	Applications	Number of Outputs	DC Voltage - Input (Min) [Min]	Approval Agency	Power (Watts)	Features	Voltage - Isolation
TDK Corporation DRL60-24-1	54 mm	55.6 mm	90.9 mm	2.19 in	2.13 in	3.58 in	2.5 A	264 VAC	85 VAC	24 V	90 %	-20 °C	71 °C	373 V	AC or DC	Hazardous Locations ITE (Commercial)	1	120 V	CE	60 W	Adjustable Output Universal Input	3000 V
TDK Corporation DRL60-15-1	54 mm	55.6 mm	90.9 mm	2.19 in	2.13 in	3.58 in	3.6 A	264 VAC	85 VAC	15 V	87 %	-20 °C	71 °C	373 V	AC or DC	Hazardous Locations ITE (Commercial)	1	120 V	CE	54 W	Adjustable Output Universal Input	3000 V
