2314929 Series

Catalog

5P,2MM,B-B,REC,SRHZ,2.1,0.38AU,T

Part	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Contact Material	Voltage Rating	Mounting Type	Insulation Height	Insulation Height	Contact Shape	Contact Finish - Post	Connector Type	Pitch - Mating [x]	Pitch - Mating [x]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Current Rating (Amps)	Insulation Color	Operating Temperature [Max]	Operating Temperature [Min]	Contact Length - Post	Contact Length - Post	Number of Positions Loaded	Number of Rows	Material Flammability Rating	Termination	Contact Finish - Mating	Insulation Material
TE Connectivity Raychem Cable Protection 2314929-5	Female Socket	15 µin	0.38 µm	Push-Pull	Phosphor Bronze	125 VDC	Through Hole Right Angle	2.1 mm	0.083 "	Square	Tin	Receptacle	0.079 in	2 mm	0.3 µm	12 µin	2 A	Black	125 °C	-40 °C	0.083 in	2.11 mm	All	1	UL94 V-0	Solder	Gold	Liquid Crystal Polymer (LCP)
